Applications:

Hazardous locations of zones 2 (gas) and 22 (dust) for illumination of escape routes  and for identification of escape routes.

Design:

Housing: Die-cast aluminium, natural finish, all electrical components integrated in the housing, wired ready for connection.

Cover: Polycarbonate opalescent white, (W), foamed silicone gasket. (Pictograms  if required – to be ordered separately, see accessories).

Connection terminal: 3 or 4 poles, clamping range max. 2.5 mm2.

Cable entries: 1 cable gland  M20 x 1.5 on the front side.

Mounting: 2 outer fixing points.

Please download the catalogue to get more information.  → nD8611.pdf
